meratdr1/4
MERSEN CANADA TORONTO INC ATDR14 FUSE CL CC 1/4A 600VTIME DELAY
meratdr1/4
MERSEN CANADA TORONTO INC ATDR14 FUSE CL CC 1/4A 600VTIME DELAY
Price
$7.56
/ EA
Inventory
Available for backorder
117for pick up at
Burlington
Manufacturer:MERSEN CANADA TORONTO INC
Manufacturer #:ATDR14
Description
Amp-Trap 2000 time-delay ATDR small-dimension fuses provide IEC Type 2 "no damage" protection to your facility's increasingly sensitive branch circuit components and small motors - minimizing the risk of fault-related damage. ATDR Class CC fuses deliver the best time-delay characteristics in their class with excellent cycling ability for small motor loads.
Specifications
| Brand Name | Ferraz Shawmut | Item Name | Time Delay Fuse |
| Series | ATDR | Voltage Rating | 600 VAC, 300 VDC |
| Amperage Rating | 0.25 A | Interrupt Rating | 100 kA at 300 VDC, 200 kA at 600 VAC |
| Fuse Class | Class CC | Body Style | Cylindrical |
| Mounting Type | Holder | Dimensions | 13/32 in dia x 1-1/2 in L |
| Element Type | Dual | Indication | Non-Indicating |
| Contact Material | Copper | Construction | Melamine |
| Standards | CSA Certified, C22.2 No. 248.4, UL E2137, UL Listed | Application | For Small Motors, Contactors, Lighting, Heating, General Loads, Branch Circuit Protection |
